Emi - Cariboni Group
Emi
Emi

Wall-Mounted

Emi

Emi was designed for accent lighting of border surfaces and transit spaces between urban interiors and exteriors: thresholds, walls, niches, arcades, portals and windows.

Plus

Design

Design

Products in the Emi line have been designed to respect the aesthetics of the illuminated architecture. For this reason it features linear, simple, clean shapes and very small sizes, with a height of about 5 cm.
Emi
Emi
Light quality

Light quality

Emi is available in two different configurations: BL, a light blade with a semicircular aperture, and AD, a washer with a wide-beam asymmetrical distribution. The BL version creates luminous lines to emphasise the perimeters of openings or to identify and outline transit areas. The AD version is ideal for enhancing architectural niches and decorative elements on historical facades.
Flexibility

Flexibility

The fastening system designed for the Emi line allows it to be tilted by up to 5° to compensate for sloping installation surfaces. The Emi line has two access points for the power supply cable: bottom or side. Side access is designed for connection to exposed electrical systems, typical of installation on historical facades.
Easy to install

Easy to install

Emi has an ultra dry system: the outer cover is independent from the sealing system and acts directly on the body to avoid the risk of infiltration when installed on uneven surfaces.
Emi
DURABLE

DURABLE

The product is robust and reliable. Components, materials and finishes have been chosen to last a long time and resist corrosion, infiltration and mechanical impact.
REPAIRABLE

REPAIRABLE

The source and the power supply and control unit can be replaced for maintenance and to update the product in order to extend its service life.
RECYCLABLE

RECYCLABLE

The main product and the packaging materials are recyclable. No adhesives are used, so components can be easily divided for separate disposal.
Accent Lighting

Accent Lighting

News 2021 - Light to arouse emotions. Four new products to design walls, thresholds, buildings, architectures and urban spaces with light.
LEAF THROUGH THE BROCHURE
Accent Lighting

Projects

Optics

Fitting flux

140 lm -> 160 lm

Fitting efficiency

30 lm/W -> 40 lm/W

Ambient temperature

-30°C +50°C

Weight

0.60 kg

Colour temperature (CCT)

3000 K,  4000 K

Colour rendering index (CRI)

≥ 80

Chromatic consistency (SDCM)

≤ 3

Electrical connection

pre-wiring with outgoing cable L=1,5 m. Double access point for the power cable: bottom or side. The side inlet is designed to allow the connection to visible electrical installations, typical of historic facades.

Source lifetime

>100.000h @Ta25°C L80B10

Driver

included

Labels and certifications

CE

Body

die-cast aluminium alloy UNI EN AB 47100 (copper content < 1%)

Lenses

high-transparency PMMA

Finish

phospho-chromatation treated and polyester powder-coated in 16 phases to increase weather resistance

Colours

Grey RAL9006

Sablé 100 Noir

White RAL9003

Corten

GROUP MANAGEMENT

DALI control

GROUP MANAGEMENT
This is a digital type control system where every device is assigned a unique address that allows the individual light points to be controlled and the control units to be created.

Design data / Download files

Leaf through the catalogue

Discover all our products and their configurations.

Product codes

Filter by:

Fitting flux (lm)
140 160
Fitting power (W)
4 4.7
Colour temperature
Source
Colour rendering index
Optics
Colour
Options
Flux regulation options
Configuration available on request:

Contact us for any specific requirements, our lighting and sales consultants will help you.

Tel. (+39) 039.95211 Fax (+39) 039.587812 e-mail info@caribonigroup.com
Product codes Options Source Optics Lm out W tot K Download
06EM1A13058A ON-OFF LED blade 5°x180° 160 4.7 4000
06EM1A13058C ON-OFF LED blade 5°x180° 160 4.7 4000
06EM1A13058D ON-OFF LED blade 5°x180° 160 4.7 4000
06EM1A13058U ON-OFF LED blade 5°x180° 160 4.7 4000
06EM1A13058AV DALI LED blade 5°x180° 160 4 4000
06EM1A13058CV DALI LED blade 5°x180° 160 4 4000
06EM1A13058DV DALI LED blade 5°x180° 160 4 4000
06EM1A13058UV DALI LED blade 5°x180° 160 4 4000
06EM1A13958A ON-OFF LED blade 5°x180° 150 4.7 3000
06EM1A13958C ON-OFF LED blade 5°x180° 150 4.7 3000
06EM1A13958D ON-OFF LED blade 5°x180° 150 4.7 3000
06EM1A13958U ON-OFF LED blade 5°x180° 150 4.7 3000
06EM1A13958AV DALI LED blade 5°x180° 150 4 3000
06EM1A13958CV DALI LED blade 5°x180° 150 4 3000
06EM1A13958DV DALI LED blade 5°x180° 150 4 3000
06EM1A13958UV DALI LED blade 5°x180° 150 4 3000
06EM2A13059A ON-OFF LED AS-D 150 4.7 4000
06EM2A13059C ON-OFF LED AS-D 150 4.7 4000
06EM2A13059D ON-OFF LED AS-D 150 4.7 4000
06EM2A13059U ON-OFF LED AS-D 150 4.7 4000
06EM2A13959A ON-OFF LED AS-D 140 4.7 3000
06EM2A13959C ON-OFF LED AS-D 140 4.7 3000
06EM2A13959D ON-OFF LED AS-D 140 4.7 3000
06EM2A13959U ON-OFF LED AS-D 140 4.7 3000
06EM2A13059AV DALI LED AS-D 150 4 4000
06EM2A13059CV DALI LED AS-D 150 4 4000
06EM2A13059DV DALI LED AS-D 150 4 4000
06EM2A13059UV DALI LED AS-D 150 4 4000
06EM2A13959AV DALI LED AS-D 140 4 3000
06EM2A13959CV DALI LED AS-D 140 4 3000
06EM2A13959DV DALI LED AS-D 140 4 3000
06EM2A13959UV DALI LED AS-D 140 4 3000
